Huawei WLA220W01 Power Lightning Arrester,20KA,1.8KV,220V,Terminal,Guideway Mounting Price in Dubai UAE
by
Huawei
SKU: WLA220W01
|
Specifications
|
||
|---|---|---|
| Model | WLA220W01 (Huawei Part No. 19020062) | |
| Type | Power Lightning Arrester / Surge Protector | |
| Nominal Voltage | 220 V AC | |
| Maximum Continuous Operating Voltage (Uc) | 385 V AC | |
| Nominal Discharge Current (In) | 20 kA (8/20 μs) | |
| Maximum Discharge Current (Imax) | 40 kA (8/20 μs) | |
| Protection Level (Up) | 1.8 kV | |
| Mounting Type | Guideway Mounting (DIN Rail Compatible) | |
| Status Indication | Four bi-color (red/green) LEDs for operational status | |
| Operating Temperature Range | -40°C to +60°C | |
| Weight | Approximately 0.5 kg | |
| Dimensions (H x W x D) | 72 mm x 90 mm x 65 mm (2.83 in. x 3.54 in. x 2.56 in.) | |
| Certifications | CE, RoHS | |
| Application | Suitable for use in telecommunications, data centers, and enterprise networks | |
|
Specifications
|
||
|---|---|---|
| Model | WLA220W01 (Huawei Part No. 19020062) | |
| Type | Power Lightning Arrester / Surge Protector | |
| Nominal Voltage | 220 V AC | |
| Maximum Continuous Operating Voltage (Uc) | 385 V AC | |
| Nominal Discharge Current (In) | 20 kA (8/20 μs) | |
| Maximum Discharge Current (Imax) | 40 kA (8/20 μs) | |
| Protection Level (Up) | 1.8 kV | |
| Mounting Type | Guideway Mounting (DIN Rail Compatible) | |
| Status Indication | Four bi-color (red/green) LEDs for operational status | |
| Operating Temperature Range | -40°C to +60°C | |
| Weight | Approximately 0.5 kg | |
| Dimensions (H x W x D) | 72 mm x 90 mm x 65 mm (2.83 in. x 3.54 in. x 2.56 in.) | |
| Certifications | CE, RoHS | |
| Application | Suitable for use in telecommunications, data centers, and enterprise networks | |
