APC APTF20KW01 WW 20KVA Isolation Transformer – High Efficiency Power Protection Price in Dubai UAE
by
APC
SKU: APTF20KW01
| Category | Specification |
|---|---|
| Model | APTF20KW01 |
| Product Type | Isolation / Step‑Down Transformer |
| Power Rating | 20 kVA / 20,000 VA |
| Nominal Input Voltage | Multiple selectable voltages (e.g., 200 V, 208 V, 230 V, 400 V, 415 V AC) |
| Nominal Output Voltage | Multiple selectable output voltages (e.g., 100 V, 120 V, 200 V, 208 V, 230 V AC) |
| Input Frequency Range | 45 – 65 Hz |
| Input Connections | Hard‑wire options (e.g., 3‑wire or 4‑wire configurations) |
| Output Connections | Hard‑wire options (e.g., 3‑wire or 4‑wire configurations) |
| Maximum Line Current | ~100 A |
| Efficiency (Full Load) | Typically high efficiency (~96 %) |
| Mounting Type | Rack‑mountable chassis |
| Rack Height | 4U |
| Form Factor | Rack‑mount transformer |
| Approx. Dimensions | ~175 mm (H) × ~432 mm (W) × ~757 mm (D) |
| Net Weight | Approx. 118 kg |
| Color | Black |
| Operating Temperature | 0 °C to 40 °C |
| Operating Humidity | 0 – 95 % RH |
| Operating Altitude | Up to ~3048 m |
| Certifications | Safety and EMC standards (e.g., CSA, UL, EN classes) |
| Typical Use | Isolation and voltage conversion ahead of UPS or critical IT loads |
