Specifications
|
||
|---|---|---|
| CPU | ||
| CPU Model | AMD Ryzen V1500B | |
| CPU Quantity | 1 | |
| CPU Core | 4 | |
| CPU Architecture | 64-bit | |
| CPU Frequency | 2.2 GHz | |
| Hardware Encryption Engine | Not specified | |
| Memory | ||
| System Memory | 4 GB DDR4 ECC SODIMM | |
| Memory Module Pre-installed | 4 GB (4 GB x 1) | |
| Total Memory Slots | 2 | |
| Maximum Memory Capacity | 32 GB (16 GB x 2) | |
| Notes | Synology recommends using Synology memory for optimal compatibility. | |
| Storage | ||
| Drive Bays | 6 | |
| Maximum Drive Bays with Expansion Unit | 16 (DX517 x 2) | |
| M.2 Drive Slots | 2 (NVMe) | |
| Compatible Drive Type | 3.5″ SATA HDD, 2.5″ SATA HDD, 2.5″ SATA SSD, M.2 2280 NVMe SSD | |
| Hot Swappable Drive | Not supported for M.2 SSD slots | |
| Notes | Compatible drive types tested but not indicating max connection speed. | |
| External Ports | ||
| RJ-45 1GbE LAN Port | 4 | |
| USB 3.2 Gen 1 Port | 3 | |
| Expansion Port | 2 | |
| Expansion Port Type | eSATA | |
| Notes | USB 3.0 renamed to USB 3.2 Gen 1 in 2019. | |
| PCIe | ||
| PCIe Expansion | 1 x Gen3 x8 slot (x4 link) | |
| Appearance | ||
| Size (Height x Width x Depth) | 166 mm x 282 mm x 243 mm | |
| Weight | 5.1 kg | |
| Others | ||
| System Fan | 92 mm x 92 mm x 2 pcs | |
| Fan Speed Mode | Full-Speed Mode, Cool Mode, Quiet Mode | |
| Easy Replacement System Fan | Yes | |
| Brightness Adjustable Front LED Indicators | Not specified | |
| Power Recovery | Not specified | |
| Noise Level | 25.2 dB(A) | |
| Scheduled Power On / Off | Not specified | |
| Wake on LAN / WAN | Not specified | |
| Power Supply Unit / Adapter | 250 watts | |
| AC Input Power Voltage | 100V to 240V AC | |
| Power Frequency | 50/60 Hz, Single Phase | |
| Power Consumption | 51.22 watts (Access), 25.27 watts (HDD Hibernation) | |
| British Thermal Unit | 174.77 BTU/hr (Access), 86.22 BTU/hr (HDD Hibernation) | |
| Notes | Power consumption tested with fully loaded system with Western Digital 1TB WD10EFRX hard drives. Noise level testing in idle state. | |
| Temperature | ||
| Operating Temperature | 0°C to 40°C (32°F to 104°F) | |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
| Certification | FCC, CE, BSMI, VCCI, RCM, EAC, CCC, KC | |
| Warranty | 3-year hardware warranty, extendable to 5 years | |
| Notes | Warranty starts from the purchase date. Extended Warranty Plus available in select regions. | |
| Environment | RoHS Compliant | |
| Packaging Content | Main Unit X 1, Accessory Pack X 1, AC Power Cord X 1, RJ-45 LAN Cable X 2, Quick Installation Guide X 1 | |
| Optional Accessories | DDR4 ECC SODIMM, Expansion Units, Enterprise Series 3.5″ SATA HDD, Plus Series 3.5″ SATA HDD, Enterprise Series 2.5″ SATA SSD, Enterprise Series M.2 2280 NVMe SSD, 25GbE Network Interface Card, 10GbE Network Interface Card | |
|
